T689.12V12 | T689.24V12

Voltage regulated power supply 12W 12V-24V DC

Power supplies

Unwired voltage regulated power supply 12W 12V-24V DC

Wiring

Unwired power supply

Certifications

Product details

More information
Download

Power supply T689.12V12 | T689.24V12 - 12W, 12V-24V DC (constant voltage)

The T689.12V12 | T689.24V12 power supply is designed to provide a constant voltage of 12V-24V DC with an output of 12W, designed for LED lighting applications. This non-wired model is CE, UKCA, RoHS and CCC certified and complies with TÜV standards while providing class 2 protection. It includes protective measures such as thermal protection and safety systems against short circuits, mains overvoltages and overloads. IP20 rating is appropriate for indoor environments and offers no dimming. Perfect for applications in residential and commercial environments, such as kitchens, bathrooms, living rooms, and bedrooms, and for contract and HoReCa projects, this power supply is an effective and compliant choice for LED lighting needs.

Dimensions

Length	96 mm
Width	46 mm
Thickness	11 mm

IP Rate

IP20

Product code	Power supply	Power	Output voltage	Output current	Ta	Tc
T689.12V12	200~240V 50/60Hz	12W	12V DC		45°C	85°C
T689.24V12	200~240V 50/60Hz	12W	24V DC		45°C	85°C
